Specifications – Indoor Unit (IDU) Forward Channel Q DVB-S2X with Adaptive Coding and Modulation (ACM) Q Frequency: C-band, Ku-band, and Ka-band Q Modulation: QPSK, 8PSK, 16APSK, 32APSK, 64APSK Q Encapsulation: GSE Q Symbol rates: Up to 235 Msps Return Channel Q MF-TDMA Q LDPC FEC with efficient variable block/burst sizes Q OQPSK, QPSK, 8PSK, or 16APSK Q Symbol rate from 256 Ksps to 12 Msps Q Adaptive Coding and Modulation (ACM) capability Network Interfaces Q 4 GigE LAN ports Q USB Power Supply Q External with detachable cord Q AC Input Voltage Range: 90–264 VAC Q Input Frequency Range: 47–63 Hz Mechanical and Environmental Q Weight: 1.23 lbs (.56 kg) Q Size: 8.0″ H x 1.6″ W x 9.0″ D (20.4 cm H x 3.9 cm W x 22.7 cm D) Q Operating temperature: 0º C to +50º C Q Relative humidity: 0 to 90% (noncondensing) Other Q Radio interface: • L-band — TX: 950-2400 MHz, RX: 950-2150 MHz • Operates in C-, Ku-, or Ka-band networks Q Antennas: 74 cm, 98 cm, 120 cm, or 180 cm Q IFL cable type and length: Dual RG-6, 75 ohm, F-type connector, up to 150′ Regulatory Q Safety: UL/CSA/EN 60950-1 Q EMC: FCC Part 15 class B, ICES-003 Q RoHS-2 compliant IP Features Q Dual stack IPv4/IPv6 Q Static and Dynamic Addressing Q BGP Routing
